Hikvision DS-D5B65RB/EP 65-inch 4K Interactive Display

Description

Hikvision DS-D5B65RB/EP 65″ 4K Interactive Display

The Hikvision DS-D5B65RB/EP is a 65-inch 4K interactive display designed for modern classrooms, training environments and collaborative meeting spaces. It integrates advanced touch technology, ultra-high-definition display, video processing, network communication and intelligent control into a single all-in-one interactive teaching and presentation solution.

Featuring UHD 4K resolution of 3840 × 2160, the display delivers sharp visuals, vibrant colours and wide viewing angles. The anti-glare tempered glass surface reduces reflections while maintaining smooth and responsive touch interaction for writing, annotation and collaboration.

The display supports dual operating systems with Android 14 built in and optional Windows functionality through an OPS module. This flexible architecture allows users to run conferencing platforms, productivity tools and collaboration software easily while keeping system deployment simple. EDLA certification ensures compatibility with enterprise and educational ecosystems.

Supporting up to 50-point infrared multi-touch, multiple users can interact simultaneously for collaborative discussions, teaching or presentations. The smooth writing experience provides natural whiteboard-style interaction.

The DS-D5B65RB/EP also features Wi-Fi 6 connectivity, multiple HDMI and USB interfaces, and USB-C ports supporting display input and charging. Combined with intelligent temperature control, tempered glass protection and built-in speakers, the display is engineered for reliable long-term use in classrooms and professional meeting environments.

---

Specification

• Product Model:	DS-D5B65RB/EP
• Screen Size:	65 inch
• Backlight:	DLED
• Pixel Pitch:	0.124 (H) × 0.372 (V) mm
• Resolution:	3840 × 2160 @60 Hz
• Brightness:	450 cd/m² (Max.); 400 cd/m² (Typ.)
• Color Depth:	10 bit (8 bit + FRC)
• Display Color:	1.07 G
• Response Time:	5 ms
• Panel Type:	VA
• Contrast Ratio:	5000:1 (Static); 30,000:1 (Dynamic)
• Color Gamut:	72% NTSC (CIE1931) (Typ.)
• Refresh Rate:	60 Hz
• Viewing Angle:	178° (H) / 178° (V)
• Aspect Ratio:	16:9
• Surface Hardness:	9H (Pencil); 7 (Mohs)
• Surface Glass:	Anti-Glare Glass
• Surface Haze:	25% Haze
• Glass Bonding Method:	Zero Lamination
• Display Area:	1428.48 × 803.52 mm
• Working Duration:	7 × 16 H
• Transmittance:	88% ± 3
• Lifespan:	50,000 hours
• Touch Type:	Infrared Touch Screen
• Touch Points:	Up to 50-point multi-touch
• Touch Response Time:	≤ 2 ms
• Minimum Touch Object:	≥ 1.5 mm (≥ 90% touching area)
• Touch Precision:	± 0.5 mm (≥ 90% touching area)
• Touch Resolution:	32768 × 32768
• Operating System:	Android 14.0
• Memory:	8 GB
• Built-in Storage:	128 GB
• Processor:	Quad-core Cortex-A72 ×4 (2.2 GHz) + Quad-core Cortex-A53 ×4 (1.8 GHz)
• GPU:	Mali-G52 MC3
• HDCP Version:	2.3 / 2.2 / 1.4
• Loudspeaker:	Built-in 2 × 20 W + 25 W loudspeaker
• Bluetooth:	Bluetooth 5.4 (BLE)
• NFC:	Support card reader 13.56 MHz (ISO 14443A / ISO 14443B)
• Light Sensor:	Yes
• Video & Audio Input:	HDMI 2.1 ×3 (Front ×1, Rear ×2); VGA ×1; Audio ×1
• Video & Audio Output:	HDMI 2.1 ×1; Audio ×1; SPDIF ×1
• Control Interface:	TOUCH-USB 3.0 ×1; TOUCH-USB 2.0 ×2; RS232 ×1
• Network Interface:	LAN (1000 Mbps) ×2; Wi-Fi 6 AP & Station (2.4G / 5G)
• Data Transmission Interface:	USB 3.0 ×3; USB 2.0 ×2; Type-C ×2 (DP IN 1.4, 65 W charging)
• Power Supply:	100–240 VAC, 50/60 Hz
• Standby Consumption:	≤ 0.5 W
• Average Consumption:	< 160 W
• Working Temperature:	0 °C to 40 °C
• Working Humidity:	10%–90% RH
• VESA Mount:	600 × 400 mm
• Product Dimensions (Without Wall Attachment):	1488.5 × 893.4 × 83.0 mm
• Product Dimensions (With Wall Attachment):	1488.5 × 893.4 × 113.1 mm
• Package Dimensions:	1662 × 1062 × 223 mm
• Net Weight:	32.2 kg
• Gross Weight:	45.3 kg
